温补振荡器

共 7 结果

图片	产品系列	产品介绍	规格书
	TD14	封装尺寸：20.412.87.6;频率范围：2MHz~125MHz;工作电压：1.8V~5.0V;频率精度（25℃）：±0.2ppm~±2.0ppm;输出模式：Sinewave Clipped Sinewave HCMOS/TTL;工作温度：-40℃~+90℃;
	T119	封装尺寸：11.49.61.85;频率范围：8MHz~100MHz;工作电压：1.8V~5.0V;频率精度（25℃）：±0.2ppm~±2ppm;输出模式：Clipped Sinewave;工作温度：-40℃~+85℃;
	T22	封装尺寸：2.52.00.85;频率范围：9.5MHz~60MHz;工作电压：1.8V~5.0V;频率精度（25℃）：±0.2ppm~±2.0ppm;输出模式：Clipped Sinewave HCMOS/TTL;工作温度：-40℃~+90℃;
	T32	封装尺寸：3.22.51.0;频率范围：9.5MHz~60MHz;工作电压：1.8V~5.0V;频率精度（25℃）：±0.2ppm~±2.0ppm;输出模式：Clipped Sinewave HCMOS/TTL;工作温度：-40℃~+90℃;
	T53	封装尺寸：5.03.21.5;频率范围：5MHz~100MHz;工作电压：1.8V~5.0V;频率精度（25℃）：0~±2.0ppm;输出模式：Clipped Sinewave CMOS;工作温度：-55℃~+95℃;
	TT75	封装尺寸：7.05.01.9;频率范围：5MHz~100MHz;工作电压：1.8V~5.0V;频率精度（25℃）：0~±2.0ppm;输出模式：Clipped Sinewave CMOS;工作温度：-55℃~+95℃;
	TF75	封装尺寸：7.05.01.9;频率范围：5MHz~100MHz;工作电压：1.8V~5.0V;频率精度（25℃）：0~±2.0ppm;输出模式：Clipped Sinewave HCMOS/TTL;工作温度：-55℃~+95℃;

共 7 结果

展开
